· steel reinforcement corrosion detector adopts the principle of polarized electrode to measure the surface potential of concrete through copper/copper sulfate reference electrode, and judge whether the steel reinforcement is corroded and the degree of corrosion according to the potential generated by steel reinforcement corrosion or the potential gradient formed.
The host parameter | |
Waterproof rating | IP65 |
Screen size | 5 inches |
Size | 195 * 140 * 45 mm |
Weight | 0.8 kg |
Potential electrode | |
Size | Φ 30 mm x 120 mm |
Weight | 100 g |
Power supply mode | built-in lithium battery |
Potential measurement range | ±1000mV |
The test accuracy | 1mV |
The measuring point spacing | 1 ~ 100cm |
The data storage capacity | 5,400 survey areas / 228,000 survey point data |
